Installation IW17
High performance custom installation in-wall loudspeaker
Installation IW17
High performance custom installation in-wall loudspeaker. High performance architectural audio with Dynaudio sound quality begins here.
The IW17 features the core technologies Dynaudio has become renowned for: A geometrically optimized Magnesium Silicate Polymer (MSP) cone membrane, a specially coated soft dome tweeter and a high quality crossover comprised of select components.
To make the IW 17 both cost effective and easy to install, the frame construction is built of lightweight yet rigid injection-moulded plastic.
The IW 17 is intended for in-wall installations and can be used for almost any high quality stereo, multi-room, or multi-channel audio application.
![DYN_IW17_front](https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_front.png?width=400&name=DYN_IW17_front.png 400w, https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_front.png?width=600&name=DYN_IW17_front.png 600w, https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_front.png?width=900&name=DYN_IW17_front.png 900w, https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_front.png?width=2000&name=DYN_IW17_front.png 2000w)
![DYN_IW17_close_1](https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_close_1.jpg?width=400&name=DYN_IW17_close_1.jpg 400w, https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_close_1.jpg?width=600&name=DYN_IW17_close_1.jpg 600w, https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_close_1.jpg?width=900&name=DYN_IW17_close_1.jpg 900w, https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_close_1.jpg?width=2000&name=DYN_IW17_close_1.jpg 2000w)
![DYN_IW17_side2](https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_side2.png?width=400&name=DYN_IW17_side2.png 400w, https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_side2.png?width=600&name=DYN_IW17_side2.png 600w, https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_side2.png?width=900&name=DYN_IW17_side2.png 900w, https://14515867.fs1.hubspotusercontent-na1.net/hub/14515867/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_side2.png?width=2000&name=DYN_IW17_side2.png 2000w)
IW17
Specifications
- Status Current
- Segment Custom Install
- Series Legacy
- Type In-wall
- Sensitivity (dB @ 2.83V/1m) 88
- Long Term Power 100
- Rated Impedance (Ohm) 4
- Lower Cutoff (Hz @ +/- 3 dB) 45
- Upper Cutoff (kHz @ +/- 3 dB) 25
- Crossover 2-way
- Tweeter 28 mm soft dome
- Midrange/Woofer 17 cm MSP
- Weight kg 1.7
- Weight lbs 3.7
- Width mm 195
- Height mm 289
- Depth mm 105
- Width inches 7 2/3
- Height inches 11 3/8
- Depth inches 4
![DYN_IW17_side2](https://dynaudio.com/hs-fs/hubfs/Dynaudio/Custom%20Install/Legacy/DYN_IW17_side2.png?width=1200&height=1200&name=DYN_IW17_side2.png)
