The Evidence Master is comprised of three individual interlocking sections.
The technically identical upper and lower cabinet sections house the bass drive units, while the middle section contains the midrange and treble drive units as well as the crossover, the latter being further isolated within its own individual sub-compartment. This construction offers a tremendous performance advantage, as each section can be optimized for the differing requirements of precise bass, midrange and high frequency reproduction.
The middle section features a massive CNC-machined solid aluminum baffle which houses two special Dynaudio MSP (Magnesium Silicate Polymer) cone midrange drivers and two perfectly matched and meticulously selected Dynaudio coated soft-dome tweeters.
The elegant design of the aluminum baffle is a direct result of geometric optimization for absolutely perfect sound dispersion. The mechanical properties of aluminum, in conjunction with the mass of the middle section guarantee perfect resonance control – reproduction of high frequencies remains completely uncolored so even the finest musical details are precisely resolved.
- Status Current
- Segment Home
- Range Evidence
- Type Floorstand
- Sensitivity (dB @ 2.83V/1m) 92
- IEC Power Handling (Watt) 600
- Rated Impedance (Ohm) 4
- Lower Cutoff (Hz @ +/- 3 dB) 27
- Upper Cutoff (kHz @ +/- 3 dB) 26
- Box Principle Bass reflex rear ported
- Crossover 3 (5) way
- Crossover Frequency (Hz) (250),400,2500,(7500) Hz
- Crossover Topology 1st order
- Tweeter 2x 28mm Esotar
- Midrange 2x15 cm MSP
- Woofer 4x20 cm MSP
- Weight kg 135
- Weight lbs 297 5/8
- Width mm 240
- Height mm 2050
- Depth mm 580
- Width inches 9 4/8
- Height inches 80 6/8
- Depth inches 22 7/8
- Width mm incl. feet/grill 450
- Height mm incl. feet/grill 2050
- Depth mm incl. feet/grill 580
- Width inches incl. feet/grill 17 6/8
- Height inches incl. feet/grill 80 6/8
- Depth inches incl. feet/grill 22 7/8
- Grille Black
- Baffle Aluminium
- Baffle DDC
