- Status Discontinued
- Segment Pro
- Series AIR
- Type Subwoofer
- Digital inputs TC Link
- Amplifier Power (W) 500W
- AC Power Input 100-120 V/200-240 V 50/60 Hz
- Lower Cutoff (Hz @85 dB +/- 3 dB) 22
- Upper Cutoff (Hz @ 85dB +/- 3 dB) 200
- Maximum SPL (dB) 117
- Box Principle Front-loaded bass reflex
- Woofer 2x10in MSP
Air + Air Software series
- Status:
- Segment:
- Series:
- Type:
- Digital inputs:
- Amplifier Power (W):
- AC Power Input:
- Lower Cutoff (Hz @85 dB +/- 3 dB):
- Upper Cutoff (Hz @ 85dB +/- 3 dB):
- Maximum SPL (dB):
- Box Principle:
- Woofer:
AIR BASE-1
- Discontinued
- Pro
- AIR
- Subwoofer
- TC Link
- 200W
- 100-120 V/200-240 V 50/60 Hz
- 25
- 120
- 113
- Front-loaded bass reflex
- 10in MSP
AIR BASE 12
- Discontinued
- Pro
- AIR
- Subwoofer
- TC Link
- 500W
- 100-120 V/200-240 V 50/60 Hz
- 22
- 200
- 117
- Bass reflex. Downfiring port
- 12in MSP
AIR BASE-2
- Discontinued
- Pro
- AIR
- Subwoofer
- TC Link
- 500W
- 100-120 V/200-240 V 50/60 Hz
- 22
- 200
- 117
- Front-loaded bass reflex
- 2x10in MSP
AIR BASE 24
- Discontinued
- Pro
- AIR
- Subwoofer
- TC Link
- 700W
- 100-120 V/200-240 V 50/60 Hz
- 20
- 200
- 120
- Bass reflex. Downfiring port
- 2x12in MSP
