BM12 mkIII
BM12 mkIII
The BM12 mkIII expands on the legacy of the classic BM12A design.
Introduction
The BM12 mkIII expands on the legacy of the classic BM12A design.
The BM12 mkIII expands on the legacy of the classic BM12A design. Re-voiced around Dynaudio's next generation waveguide, the BM12 mkIII has been designed around highly efficient hand-crafted neodymium drivers, providing faithful transient response and an SPL of 123 dB for larger listening environments.
Large diameter voice coil surrounds the magnet for superior linearity. Aluminum voice coil former and wire are low mass so transient response is quick and accurate. Diaphragm and dust cap are moulded as one piece in patented low-mass, highly rigid Magnesium Silicate Polymer providing unrivaled accuracy.



BM12 mklll
Specifications
- Status Discontinued
- Segment Pro
- Series BM mkIII
- Type Nearfield Monitor
- Analog inputs XLR
- Maximum SPL (1m, pair) 123
- Amplifier Power Woofer (W) 100
- Amplifier Power Tweeter (W) 50
- AC Power Input 100-240V 50/60Hz
- Max Stand-by Power Consumption (W) 0.3
- Max Power Consumption (W) 130
- Box Principle Rear-loaded bass reflex
- Crossover 2-way DSP-based
- Crossover Frequency (Hz) 1500 Hz
- Crossover Topology 1st order
- Tweeter 1.1in soft dome
- Midrange/Woofer 8in MSP
- Weight kg 12.5
- Weight lbs 27 4/8
- Width mm 234
- Height mm 369
- Depth mm 328
- Width inches 9 2/8
- Height inches 14 4/8
- Depth inches 12 7/8
