Delta 80

Maximum power, ready to rack

The Delta series philosophy: reliability, trust and transparent amplification of your mix

Delta 80

Every model uses the highest-quality power-amplifier technology – so you know for a fact that what goes in, comes out exactly as intended. Only louder.

The 2U Delta 80 yields a staggering 4x 2000W of power at 4 ohms – or 2x 4000W when bridged. And it does so without breaking a sweat, while delivering enviably low distortion and noise figures. For instance, THD is as little as <0.18% at 1kHz.

Analogue or AoIP via Dante? Delta 80 handles up to four channels; a future-proof system that can keep up with whatever your studio throws at it. When using Dante, your audio is converted by 24-bit/96kHz DACs.

You also get back-up amplifier redundancy, ensuring that your production can move ahead almost regardless of what might happen on the amp side of your studio.

Want a stereo four-way system? Just connect to a Delta DSP amplifier with a single Cat 5 cable to eliminate the need for external processing.

Specifications

Digital I/O

Networking	2x RJ45	1000BASE-T, Dante, AES67
Thunderbolt	2x Thunderbolt 3	2x15 Watts PD
ADAT	Toslink 2x In, 2x Out	16 channels total, can be configured as S/PDIF
AES3	DB25	8CH AES3 (16 Audio Channels)
Word Clock	2x BNC	WC In/Out
MADI	2x BNC	MADI In/Out

Analog I/O

Headphone	2x TRS (Front)	18-600 Ohm
Expansion	DAD Expansion Modules	1 available slot

Power

C13	90-260 VAC (Max 120W)

Dimensions

Chassis	19", 1 RU
Depth	32 cm / 12.6"
Width	43.5 cm / 17.2"
Weight	2.8 kg / 6.5 lbs

DynaudioAcousticsAmplifiers_Delta80_02_1200x1200px-1

DynaudioAcousticsAmplifiers_Delta80_03_1200x1200px

Status Current
Segment Pro
Series Acoustic Amplifiers
Type Amplifier
Number of channels 4
Output Power: (per channel)*
8 ohms 1000W
4 ohms 2000W
2.7 ohms 2200W
2 ohms 2000W*
Output Power: (bridged)
8 ohms 4000W
4 ohms 4000W
THD%: (@1dB below max output)
@ 1kHz < 0.18%
20Hz to 20kHz < 0.2%
Gain/Sensivity
Gain 32dB
Sensitivity (for max power) 8.2dBu
Frequency response 20Hz to 20kHz (+ 0/- 0.5dB)
Power Consumption: (< 5W in standby)
Nominal @ 240v into 4 ohms 4.1A
Nominal @ 120v into 4 ohms 8.2A
Dimensions (HxWxD) / Weight
(2 units) (mm) 88 x 482 x 428
Single Box (UK shipping) (2 units) (mm) 230 x 580 x 560
Double Box (outside UK) (2 units) (mm) 250 x 610 x 600
Weight kg 10.1
Weight lbs 22.3
Boxed weight (kg) 11.6
Boxed weight (lbs) 25.6
* 2.7 ohm power quoted for highest single ended output and greatest efficiency (3 x 8 ohm parallel drivers). Amplifier is stable with 2 ohm Loads but output will be reduced.
